Features

• Collinear Load Test 50kg, 100pounds
• Dual Voltage 12 or 24 VDC (optional)
• The Standard Voltage is 12VDC when Finished
• MOV Provides Reverse Current Protection
• Low Power, Environmental Protection
• Anti-Residual Magnetism Designed
• Professional Design, Dual Insulative Housing
• Shunt and Defend the Cigarette Door Automatically During the Fire Alarm
• With the Hand Moves and Closes the Door to Release the Button
• CE Certificate by European Union

Parameters

• Dimensions: 118Lx92Wx120H(mm)

• Holding Force: 50kg (100Lbs)

• Voltage: 12/24VDC+10%

• Current Draw: 12V/100mA 24V/50mA

• Optional: The Hand Moves and Closes the Door to Release the Button

• Suitable for: All Kind of the Single & Double Smoke proof Door

• Surface Temp: ≤+20°C

• Operating Temp: -10~+55°C(14-131F)

• Suitable Humidity: 0~90%(non-condensing)

• Finishes for Shell: High-Temperature Paint and Environmental Protection Zinc

• Finishes for Armature: Zinc

• Weight: 0.96kg
